Suspending cloud backup of a NAS that cannot be reached

I use CrashPlan for cloud backups. In 2018 they stopped their Home solution, so I switched to their Business plan.

It works very well on Linux, Windows and Mac, but it was always a bit fickle on my QNAP NAS. There is a qpkg package for CrashPlan, and there are lots of posts on the QNAP support forum. After 2018, none of the solutions to run a backup on the NAS itself stopped working. So I gave up, and I didn’t have a backup for almost 4 years.

Now that I have mounted most of the network shares on my local filesystem, I can just run the backup on my pc. I made 3 different backup sets, one for each of the shares. There’s only one thing that I had to fix: if Crashplan runs when the shares aren’t mounted, then it thinks that the directories are empty, and it will delete the backup on the cloud storage. As soon as the shares come back online, the files are backed up again. It doesn’t have to upload all files again, because Crashplan doesn’t purge the files on it’s cloud immediately, but the file verification still happens. That takes time and bandwidth.

I contacted CrashPlan support about this issue, and this was their reply:

I do not believe that this scenario can be avoided with this product – at least not in conjunction with your desired setup. If a location within CrashPlan’s file selection is detached from the host machine, then the program will need to rescan the selection. This is in inherent drawback to including network drives within your file selection. Your drives need to retain a stable connection in order to avoid the necessity of the software to run a new scan when it sees the drives attached to the device (so long as they’re within the file selection) detach and reattach.

Since the drive detaching will send a hardware event from the OS to CrashPlan, CrashPlan will see that that hardware event lies within its file selection – due to the fact that you mapped your network drives into a location which you’ve configured CrashPlan to watch. A hardware event pointing out that a drive within the /home/amedee/Multimedia/ file path has changed its connection status will trigger a scan. CrashPlan will not shut down upon receiving a drive detachment or attachment hardware event. The program needs to know what (if anything) is still there, and is designed firmly to track those types of changes, not to give up and stop monitoring the locations within its file selection.

There’s no way around this, aside from ensuring that you either keep a stable connection. This is an unavoidable negative consequence of mapping a network drive to a location which you’ve included in CrashPlan’s file selection. The only solution would be for you to engineer your network so as not to interrupt the connection.

Nathaniel, Technical Support Agent, Code42

I thought as much already. No problem, Nathaniel! I found a workaround: a shell script that checks if a certain marker file on the network share exists, and if it doesn’t, then the script stops the CrashPlan service, which will prevent CrashPlan from scanning the file selection. As soon as the file becomes available again, then the CrashPlan service is started. This workaround works, and is good enough for me. It may not be the cleanest solution but I’m happy with it.

I first considered using inotifywait, which listens to filesystem events like modifying or deleting files, or unmount. However when the network connection just drops for any reason, then inotifywait doesn’t get an event. So I have to resort to checking if a file exists.

#!/bin/bash
file_list="/home/amedee/bin/file_list.txt"

all_files_exist () {
    while read -r line; do
        [ -f "$line" ]
        status=$?
        if ! (exit $status); then
            echo "$line not found!"
            return $status
        fi
    done < "$file_list"
}

start_crashplan () {
    /etc/init.d/code42 start
}

stop_crashplan () {
    /etc/init.d/code42 stop
}

while true; do
    if all_files_exist; then
        start_crashplan
    else
        stop_crashplan
    fi
    sleep 60
done
  • file_list.txt contains a list of testfiles on different shares that I want to check. They all have to be present, if even only one of them is missing or can’t be reached, then the service must be stopped.
/home/amedee/Downloads/.testfile
/home/amedee/Multimedia/.testfile
/home/amedee/backup/.testfile
  • I can add or remove shares without needing to modify the script, I only need to edit file_list.txt – even while the script is still running.
  • Starting (or stopping) the service if it is already started (or stopped) is very much ok. The actual startup script itself takes care of checking if it has already started (or stopped).
  • This script needs to be run at startup as root, so I call it from cron (sudo crontab -u root -e):
@reboot /home/amedee/bin/test_cifs_shares.sh

This is what CrashPlan support replied when I told them about my workaround:

Hello Amedee,

That is excellent to hear that you have devised a solution which fits your needs!

This might not come in time to help smooth out your experience with your particular setup, but I can mark this ticket with a feature request tag. These tags help give a resource to our Product team to gauge customer interest in various features or improvements. While there is no way to use features within the program itself to properly address the scenario in which you unfortunately find yourself, as an avenue for adjustments to how the software currently operates in regards to the attachment or detachment of network drives, it’s an entirely valid request for changes in the future.

Nathaniel, Technical Support Agent, Code42

That’s very nice of you, Nathaniel! Thank you very much!

The hunt for a kernel bug, part 5

Armed with the information from my previous research on a possible kernel bug, I opened a bug report on the Ubuntu bug tracker: https://bugs.launchpad.net/ubuntu/+source/linux/+bug/1963555.

It wasn’t long until my bug got confirmed. Someone else chimed in that they had also experienced USB issues. In their case it were external drive devices. Definitely a showstopper!

As of this date, there is a beta for Ubuntu 22.04, and my hope is that this version will either include a new enough kernel (5.16 or up), or that Ubuntu developers have manually cherry-picked the commit that fixes the issue. Let’s check with the Ubuntu Kernel Team:

Ubuntu Kernel Team

Oops… based on upstream 5.15… that’s not good. Maybe they cherry-picked upstream commits? I checked https://packages.ubuntu.com/jammy/linux-generic and the kernel is currently at 5.15.0.25.27. The changelog doesn’t mention anything about xhci or usb. I guess I still have to wait a bit longer…

I have a ridiculous amount of kernels

In previous blogposts I wrote about how I found a possible bug in the Linux kernel, or more precisely, in the kernel that Ubuntu derived from the mainline kernel.

To be able to install any kernel version 5.15.7 or higher, I also had to install libssl3.

The result is that I now have 37 kernels installed, taking up little over 2 GiB disk space:

$ (cd /boot ; ls -hgo initrd.img-* ; ls /boot/initrd.img-* | wc -l)
-rw-r--r-- 1 39M mrt  9 09:54 initrd.img-5.13.0-051300-generic
-rw-r--r-- 1 40M mrt  9 09:58 initrd.img-5.13.0-19-generic
-rw-r--r-- 1 40M mrt  9 09:58 initrd.img-5.13.0-20-generic
-rw-r--r-- 1 40M mrt  9 09:57 initrd.img-5.13.0-21-generic
-rw-r--r-- 1 44M mrt 30 17:46 initrd.img-5.13.0-22-generic
-rw-r--r-- 1 40M mrt  9 09:56 initrd.img-5.13.0-23-generic
-rw-r--r-- 1 40M mrt  9 09:56 initrd.img-5.13.0-25-generic
-rw-r--r-- 1 40M mrt  9 09:56 initrd.img-5.13.0-27-generic
-rw-r--r-- 1 40M mrt  9 09:55 initrd.img-5.13.0-28-generic
-rw-r--r-- 1 40M mrt  9 09:55 initrd.img-5.13.0-30-generic
-rw-r--r-- 1 45M mrt  9 12:02 initrd.img-5.13.0-35-generic
-rw-r--r-- 1 45M mrt 24 23:17 initrd.img-5.13.0-37-generic
-rw-r--r-- 1 45M mrt 30 17:49 initrd.img-5.13.0-39-generic
-rw-r--r-- 1 39M mrt  9 09:54 initrd.img-5.13.1-051301-generic
-rw-r--r-- 1 39M mrt  9 09:54 initrd.img-5.13.19-051319-generic
-rw-r--r-- 1 37M mrt  9 09:53 initrd.img-5.13.19-ubuntu-5.13.0-22.22
-rw-r--r-- 1 37M mrt  9 09:53 initrd.img-5.13.19-ubuntu-5.13.0-22.22-0-g3ab15e228151
-rw-r--r-- 1 37M mrt  9 09:52 initrd.img-5.13.19-ubuntu-5.13.0-22.22-317-g398351230dab
-rw-r--r-- 1 37M mrt  9 09:52 initrd.img-5.13.19-ubuntu-5.13.0-22.22-356-g8ac4e2604dae
-rw-r--r-- 1 37M mrt  9 09:52 initrd.img-5.13.19-ubuntu-5.13.0-22.22-376-gfab6fb5e61e1
-rw-r--r-- 1 37M mrt  9 09:51 initrd.img-5.13.19-ubuntu-5.13.0-22.22-386-gce5ff9b36bc3
-rw-r--r-- 1 37M mrt  9 09:51 initrd.img-5.13.19-ubuntu-5.13.0-22.22-387-g0fc979747dec
-rw-r--r-- 1 37M mrt  9 09:50 initrd.img-5.13.19-ubuntu-5.13.0-22.22-388-g20210d51e24a
-rw-r--r-- 1 37M mrt  9 09:50 initrd.img-5.13.19-ubuntu-5.13.0-22.22-388-gab2802ea6621
-rw-r--r-- 1 37M mrt  9 09:50 initrd.img-5.13.19-ubuntu-5.13.0-22.22-391-ge24e59fa409c
-rw-r--r-- 1 37M mrt  9 09:49 initrd.img-5.13.19-ubuntu-5.13.0-22.22-396-gc3d35f3acc3a
-rw-r--r-- 1 37M mrt  9 09:49 initrd.img-5.13.19-ubuntu-5.13.0-22.22-475-g79b62d0bba89
-rw-r--r-- 1 37M mrt  9 09:48 initrd.img-5.13.19-ubuntu-5.13.0-23.23
-rw-r--r-- 1 40M mrt  9 09:48 initrd.img-5.14.0-051400-generic
-rw-r--r-- 1 40M mrt  9 10:31 initrd.img-5.14.21-051421-generic
-rw-r--r-- 1 44M mrt  9 12:39 initrd.img-5.15.0-051500-generic
-rw-r--r-- 1 46M mrt  9 12:16 initrd.img-5.15.0-22-generic
-rw-r--r-- 1 46M mrt 28 23:27 initrd.img-5.15.32-051532-generic
-rw-r--r-- 1 46M mrt 17 21:12 initrd.img-5.16.0-051600-generic
-rw-r--r-- 1 48M mrt 28 23:19 initrd.img-5.16.16-051616-generic
-rw-r--r-- 1 45M mrt 28 23:11 initrd.img-5.17.0-051700-generic
-rw-r--r-- 1 46M apr  8 17:02 initrd.img-5.17.2-051702-generic
37
  • Versions 5.xx.yy-zz-generic are installed with apt.
  • Versions 5.xx.yy-05xxyy-generic are installed with the Ubuntu Mainline Kernel Installer.
  • Versions 5.xx.yy-ubuntu-5.13.0-zz.zz-nnn-g<commithash> are compiled from source, where <commithash> is the commit of the kernel repository that I compiled.

The kernels in bold are the kernels where something unexpected happens with my USB devices:

  • Ubuntu kernels 5.13.23 and up – including 5.15 kernels of Ubuntu 22.04 LTS (Jammy Jellyfish).
  • Ubuntu compiled kernels, starting 387 commits after kernel 5.13.22.
  • Mainline kernels 5.15.xx.

When Ubuntu finally bases their kernel on mainline 5.16 or higher, then the USB bug will be solved.

Install libssl3 on Ubuntu versions before Jammy

Ubuntu mainline kernel packages 5.15.7 and later bump a dependency from libssl1.1 (>= 1.1.0) to libssl3 (>= 3.0.0~~alpha1).

However, package libssl3 is not available for Ubuntu 21.10 Impish Indri. It’s only available for Ubuntu 22.04 Jammy Jellyfish (which is still in beta as of time of writing) and later.

libssl3 further depends on libc6>=2.34 and debconf, but they are available in 21.10 repositories.

Here are a few different ways to resolve the dependency:

Option 1

Use apt pinning to install libssl3 from a Jammy repo, without pulling in everything else from Jammy.

This is more complicated, but it allows the libssl3 package to receive updates automatically.
Do all the following as root.

  • Create an apt config file to specify your system’s current release as the default release for installing packages, instead of simply the highest version number found. We are about to add a Jammy repo to apt, which will contain a lot of packages with higher version numbers, and we want apt to ignore them all.
$ echo 'APT::Default-Release "impish";' \
    | sudo tee /etc/apt/apt.conf.d/01ubuntu
  • Add the Jammy repository to the apt sources. If your system isn’t “impish”, change that below.
$ awk '($1$3$4=="debimpishmain"){$3="jammy" ;print}' /etc/apt/sources.list \
    | sudo tee /etc/apt/sources.list.d/jammy.list
  • Pin libssl3 to the jammy version in apt preferences. This overrides the Default-Release above, just for the libssl3 package.
$ sudo tee /etc/apt/preferences.d/libssl3 >/dev/null <<%%EOF
Package: libssl3
Pin: release n=jammy
Pin-Priority: 900
%%EOF
  • Install libssl3:
$ sudo apt update
$ sudo apt install libssl3

Later, when Jammy is officially released, delete all 3 files created above

$ sudo rm --force \
    /etc/apt/apt.conf.d/01ubuntu \
    /etc/apt/sources.list.d/jammy.list \
    /etc/apt/preferences.d/libssl3

Option 2

Download the libssl3 deb package for Jammy and install it manually with dpkg -i filename.deb.

This only works if there aren’t any additional dependencies, which you would also have to install, with a risk of breaking your system. Here Be Dragons…

Printing multiple PDF files from console with lp

Recently I wanted to print some PDF files containing sheet music. The tedious way to do that, would be to open them one by one in Evince and press the print button. Surely there must be a more efficient way to do that?

$ ls -l --human-readable *.pdf
-r--r--r-- 1 amedee amedee 217K apr 15  2020 'Arthur original.pdf'
-r--r--r-- 1 amedee amedee 197K apr 13  2020 'Canal en octobre.pdf'
-r--r--r-- 1 amedee amedee  14K apr 13  2020  DenAndro.pdf
-r--r--r-- 1 amedee amedee  42K apr 14  2020 'Doedel you do.pdf'
-r--r--r-- 1 amedee amedee  57K apr 13  2020  Flatworld.pdf
-r--r--r-- 1 amedee amedee  35K apr 16  2020 'Jump at the sun.pdf'
-r--r--r-- 1 amedee amedee 444K jun 19  2016 'Kadril Van Mechelen.pdf'
-r--r--r-- 1 amedee amedee  15K apr 13  2020  La-gavre.pdf
-r--r--r-- 1 amedee amedee  47K apr 13  2020 'Le petit déjeuner.pdf'
-r--r--r-- 1 amedee amedee 109K apr 13  2020  LesChaminoux__2016_04_24.cached.pdf
-r--r--r-- 1 amedee amedee 368K apr 13  2020 'Mazurka It.pdf'
-r--r--r-- 1 amedee amedee 591K apr 13  2020 'Narrendans uit Mater.pdf'
-r--r--r-- 1 amedee amedee 454K apr 13  2020 'Neverending jig.pdf'
-r--r--r-- 1 amedee amedee 1,1M apr 14  2020 'Red scissors.pdf'
-r--r--r-- 1 amedee amedee  35K apr 13  2020  Scottish-à-VirmouxSOL.pdf
-r--r--r-- 1 amedee amedee  76K apr 14  2020 'Tarantella Napolitana meest gespeelde versie.pdf'
-r--r--r-- 1 amedee amedee 198K apr 15  2020 'Zot kieken!.pdf'

There are 2 console commands for printing: lp and lpr. One comes from grandpa System V, the other from grandpa BSD, and both are included in CUPS. The nice thing about these commands is that they know how to interpret PostScript and PDF files. So this is going to be easy: just cd into the directory with the PDF files and print them all:

$ lp *.pdf
lp: Error - No default destination.

Oops. A quick Google search of this error message tells me that I don’t have a default printer.

Configuring a default printer

First I use lpstat to find all current printers:

$ lpstat -p -d
printer HP_OfficeJet_Pro_9010_NETWORK is idle.  enabled since za 12 mrt 2022 00:00:28
printer HP_OfficeJet_Pro_9010_USB is idle.  enabled since za 12 mrt 2022 00:00:17
no system default destination

I have a HP OfficeJet Pro 9012e printer, which Ubuntu recognizes as a 9010 series. Close enough. It’s connected over network and USB. I’m setting the network connection as default with lpoptions:

$ lpoptions -d $(lpstat -p -d | head --lines=1 | cut --delimiter=' ' --fields=2)
copies=1 device-uri=hp:/net/HP_OfficeJet_Pro_9010_series?ip=192.168.1.9 finishings=3 job-cancel-after=10800 job-hold-until=no-hold job-priority=50 job-sheets=none,none marker-change-time=0 media=iso_a4_210x297mm number-up=1 output-bin=face-down print-color-mode=color printer-commands=none printer-info printer-is-accepting-jobs=true printer-is-shared=true printer-is-temporary=false printer-location printer-make-and-model='HP Officejet Pro 9010 Series, hpcups 3.22.2' printer-state=3 printer-state-change-time=1649175159 printer-state-reasons=none printer-type=4124 printer-uri-supported=ipp://localhost/printers/HP_OfficeJet_Pro_9010_NETWORK sides=one-sided

I can then use lpq to verify that the default printer is ready:

$ lpq
HP_OfficeJet_Pro_9010_NETWORK is ready
no entries

Printing multiple files from console

I found that if I naively do lp *.pdf, then only the last file will be printed. That’s unexpected, and I can’t be bothered to find out why. So I just use ls and feed that to a while-loop. It’s quick and dirty, and using find+xargs would probably be better if there are “special” characters, but that’s not the case here.

There’s one caveat: when the PDF files are printed one by one, then the first page will be at the bottom of the paper stack, so I need to print them in reverse order.

$ ls --reverse *.pdf | while read f; do lp "$f"; done

With that command I got 17 print jobs in the printer queue, one for each file.

Now that I know how to print from console, I’ll probably do that more often. The man page of lp describes many useful printing options, like printing double sided:

$ lp -o media=a4 -o sides=two-sided-long-edge filename

The hunt for a kernel bug, part 4: git bisect

Now that I have a way to compile kernels from source, I want to find the exact commit where my input devices stop working. That means doing a git checkout of a certain commit, build the kernel, install it, reboot, select the new kernel in Grub, and see if my keyboard works. I am quite sure that I need to search between 5.13.0-22 and 5.13.0-23, but that’s still 634 commits!

$ git rev-list Ubuntu-5.13.0-22.22..Ubuntu-5.13.0-23.23 | wc --lines
634

This is where git bisect comes in. It’s sort of a wizard that guides you to find a bad commit. You tell it on which commit your software was known to work ok, and a commit where it doesn’t. It then picks a commit somewhere in the middle, you build your software and do your tests, and then tell git bisect if the result was good or bad. It will then give you a new commit to inspect, each time narrowing the search.

git-bisect-sumo-logic
git bisect

Let’s do this!

$ git bisect start
$ git bisect good Ubuntu-5.13.0-22.22
$ git bisect bad Ubuntu-5.13.0-23.23
Bisecting: 316 revisions left to test after this (roughly 8 steps)
[398351230dab42d654036847a49a5839705abdcb] powerpc/bpf ppc32: Fix BPF_SUB when imm == 0x80000000
$ git describe --long
Ubuntu-5.13.0-22.22-317-g398351230dab

In this first step, I get the 317th commit after 5.13.0-22. Let’s compile that commit:

$ time make clean olddefconfig bindeb-pkg \
    --jobs=$(getconf _NPROCESSORS_ONLN) \
    LOCALVERSION=-$(git describe --long | tr '[:upper:]' '[:lower:]')

This creates 3 .deb packages in the directory above:

$ ls -1 ../*$(git describe --long | tr '[:upper:]' '[:lower:]')*.deb
../linux-headers-5.13.19-ubuntu-5.13.0-22.22-317-g398351230dab_5.13.19-ubuntu-5.13.0-22.22-317-g398351230dab-10_amd64.deb
../linux-image-5.13.19-ubuntu-5.13.0-22.22-317-g398351230dab_5.13.19-ubuntu-5.13.0-22.22-317-g398351230dab-10_amd64.deb
../linux-libc-dev_5.13.19-ubuntu-5.13.0-22.22-317-g398351230dab-10_amd64.deb

I only need to install the headers and the image, libc-dev isn’t needed.

$ sudo dpkg --install ../linux-{headers,image}-*$(git describe --long | tr '[:upper:]' '[:lower:]')*.deb

Verify that the kernel files are in the /boot directory:

$ ls -1 /boot/*$(git describe --long | tr '[:upper:]' '[:lower:]')*
/boot/config-5.13.19-ubuntu-5.13.0-22.22-317-g398351230dab
/boot/initrd.img-5.13.19-ubuntu-5.13.0-22.22-317-g398351230dab
/boot/System.map-5.13.19-ubuntu-5.13.0-22.22-317-g398351230dab
/boot/vmlinuz-5.13.19-ubuntu-5.13.0-22.22-317-g398351230dab

Now I can reboot, select the new kernel in Grub, and test the keyboard. With commit 317, the keyboard worked, so the first bad commit has to be somewhere between commit 317 and 634:

$ git bisect good ; git describe --long
Bisecting: 158 revisions left to test after this (roughly 7 steps)
[79b62d0bba892e8367cb46ca09b623c885852c29] drm/msm/a4xx: fix error handling in a4xx_gpu_init()
Ubuntu-5.13.0-22.22-475-g79b62d0bba89

Now it’s time again for make clean olddefconfig bindeb-pkg, dpkg --install and reboot. Turns out that commit 475 was a “bad” commit (one where the keyboard didn’t work):

$ git bisect bad ; git describe --long
Bisecting: 78 revisions left to test after this (roughly 6 steps)
[c3d35f3acc3a11b726959c7b2c25ab9e46310273] USB: serial: option: add Telit LE910Cx composition 0x1204
Ubuntu-5.13.0-22.22-396-gc3d35f3acc3a

I’m not going to describe all the steps in full detail, by now you should get the gist of it. This was the sequence of steps that git bisect gave me:

  • 317: good
  • 475: bad
  • 396: bad
  • 356: good
  • 376: good
  • 386: good
  • 391: bad
  • 388: bad
  • 387: bad

And then we finally get the first bad commit, the 387th commit after 5.13.0-22, Ubuntu-5.13.0-22.22-387-g0fc979747dec:

$ git bisect bad ; git describe --long
0fc979747dece96c189bc29ef604e61afbddfa2a is the first bad commit
commit 0fc979747dece96c189bc29ef604e61afbddfa2a
Author: Pavankumar Kondeti <pkondeti@codeaurora.org>
Date:   Fri Oct 8 12:25:46 2021 +0300

    xhci: Fix command ring pointer corruption while aborting a command

    BugLink: https://bugs.launchpad.net/bugs/1951880

    commit ff0e50d3564f33b7f4b35cadeabd951d66cfc570 upstream.

    The command ring pointer is located at [6:63] bits of the command
    ring control register (CRCR). All the control bits like command stop,
    abort are located at [0:3] bits. While aborting a command, we read the
    CRCR and set the abort bit and write to the CRCR. The read will always
    give command ring pointer as all zeros. So we essentially write only
    the control bits. Since we split the 64 bit write into two 32 bit writes,
    there is a possibility of xHC command ring stopped before the upper
    dword (all zeros) is written. If that happens, xHC updates the upper
    dword of its internal command ring pointer with all zeros. Next time,
    when the command ring is restarted, we see xHC memory access failures.
    Fix this issue by only writing to the lower dword of CRCR where all
    control bits are located.

    Cc: stable@vger.kernel.org
    Signed-off-by: Pavankumar Kondeti <pkondeti@codeaurora.org>
    Signed-off-by: Mathias Nyman <mathias.nyman@linux.intel.com>
    Link: https://lore.kernel.org/r/20211008092547.3996295-5-mathias.nyman@linux.intel.com
    Signed-off-by: Greg Kroah-Hartman <gregkh@linuxfoundation.org>
    Signed-off-by: Kamal Mostafa <kamal@canonical.com>
    Signed-off-by: Stefan Bader <stefan.bader@canonical.com>

 drivers/usb/host/xhci-ring.c | 14 ++++++++++----
 1 file changed, 10 insertions(+), 4 deletions(-)
Ubuntu-5.13.0-22.22-387-g0fc979747dec

At first sight the commit description is quite cryptic, and the actual code change doesn’t tell me a lot either. But it’s a change in drivers/usb/host/xhci-ring.c, and xhci stands for eXtensible Host Controller Interface, and interface specification for USB host controllers. If it’s an issue with the USB host controller, then it makes sense that if I use 2 keyboards from different brands, neither of them would work. It also suggests that other USB devices, like external hard drives, wouldn’t work either, but that’s a bit harder to test. A keyboard is easy. Just look at NumLock LED, if it doesn’t go on then there’s an issue.

The first link in the commit description is just a long list of patches that were taken from upstream and integrated in the Ubuntu kernel, so that doesn’t help me. The second link is a thread on the kernel.org mailing list, and there it gets interesting.

kernel.org mailing list thread

Some excerpts from the thread:

This patch cause suspend to disk resume usb not work, xhci_hcd 0000:00:14.0: Abort failed to stop command ring: -110.

youling257

Thanks for the report, this is odd.
Could you double check that by reverting this patch resume start working again.
If this is the case maybe we need to write all 64bits before this xHC hardware reacts to CRCR register changes.
Maybe following changes on top of current patch could help:

Mathias Nyman

Every time a developer says “this is odd”, my alarm bells go off. 😀

Further down in the thread there is a proposed update to the change. I’m going to try that patch, but that’s for another blog post.

The hunt for a kernel bug, part 3: compiling a kernel

Compiling a Linux kernel sounds scary and complicated, but I found out it actually isn’t.

The first thing to do, is to install some prerequisites:

$ sudo apt install --yes asciidoc binutils-dev bison build-essential ccache \
    crash dwarves fakeroot flex git git-core git-doc git-email kernel-package \
    kernel-wedge kexec-tools libelf-dev libncurses5 libncurses5-dev libssl-dev \
    makedumpfile zstd
$ sudo apt-get --yes build-dep linux

Next I cloned the Ubuntu Impish repository. This takes a while…

$ git clone git://kernel.ubuntu.com/ubuntu/ubuntu-impish.git
$ cd ubuntu-impish

Now let’s see which versions are in the repository:

$ git tag --list
Ubuntu-5.11.0-16.17
Ubuntu-5.11.0-18.19+21.10.1
Ubuntu-5.11.0-20.21+21.10.1
Ubuntu-5.13.0-11.11
Ubuntu-5.13.0-12.12
Ubuntu-5.13.0-13.13
Ubuntu-5.13.0-14.14
Ubuntu-5.13.0-15.15
Ubuntu-5.13.0-16.16
Ubuntu-5.13.0-17.17
Ubuntu-5.13.0-18.18
Ubuntu-5.13.0-19.19
Ubuntu-5.13.0-20.20
Ubuntu-5.13.0-21.21
Ubuntu-5.13.0-22.22
Ubuntu-5.13.0-23.23
Ubuntu-5.13.0-24.24
Ubuntu-5.13.0-25.26
Ubuntu-5.13.0-26.27
Ubuntu-5.13.0-27.29
Ubuntu-5.13.0-28.31
Ubuntu-5.13.0-29.32
Ubuntu-5.13.0-30.33
Ubuntu-5.13.0-31.34
Ubuntu-5.13.0-32.35
freeze-20211018
freeze-20211108
freeze-20220131
freeze-20220221
v5.11
v5.13

The two tags that interest me, are Ubuntu-5.13.0-22.22 and Ubuntu-5.13.0-23.23. I’m starting with the former.

git checkout Ubuntu-5.13.0-22.22

First I copy the configuration of the current running kernel to the working directory:

$ cp /boot/config-$(uname --kernel-release) .config

I don’t want or need full debugging. That makes an enormous kernel and it takes twice as long to compile, so I turn debugging off:

$ scripts/config --disable DEBUG_INFO

I need to disable certificate stuff:

$ scripts/config --disable SYSTEM_TRUSTED_KEYS
$ scripts/config --disable SYSTEM_REVOCATION_KEYS

Next: update the kernel config and set all new symbols to their default value.

$ make olddefconfig

Then the most exciting thing can start: actually compiling the kernel!

$ make clean
$ time make --jobs=$(getconf _NPROCESSORS_ONLN) bindeb-pkg \
    LOCALVERSION=-$(git describe --long | tr '[:upper:]' '[:lower:]')
  • time is to see how long the compilation took.
  • getconf _NPROCESSORS_ONLN queries the number of processors on the computer. make will then try to run that many jobs in parallel.
  • bindeb-pkg will create .deb packages in the directory above.
  • LOCALVERSION appends a string to the kernel name.
  • git describe --long shows how far after a tag a certain commit is. In this case: Ubuntu-5.13.0-22.22-0-g3ab15e228151
    • Ubuntu-5.13.0-22.22 is the tag.
    • 0 is how many commits after the tag. In this case it’s the tag itself.
    • 3ab15e228151 is the abbreviated hash of the current commit.
  • tr '[:upper:]' '[:lower:]' is needed because .deb packages can’t contain upper case letters (I found out the hard way).

Now go grab a coffee, tea or chai latte. Compilation took 22 minutes on my computer.

Chai latte

When the compilation is done, there are 3 .deb packages in the directory above:

$ ls -1 ../*.deb
../linux-headers-5.13.19-ubuntu-5.13.0-22.22-0-g3ab15e228151_5.13.19-ubuntu-5.13.0-22.22-0-g3ab15e228151-21_amd64.deb
../linux-image-5.13.19-ubuntu-5.13.0-22.22-0-g3ab15e228151_5.13.19-ubuntu-5.13.0-22.22-0-g3ab15e228151-21_amd64.deb
../linux-libc-dev_5.13.19-ubuntu-5.13.0-22.22-0-g3ab15e228151-21_amd64.deb

Install the linux-headers and the linux-image packages, you don’t need the libc-dev package.

$ sudo dpkg --install \
    ../linux-{headers,image}-*$(git describe --long | tr '[:upper:]' '[:lower:]')*.deb

The kernel is now installed in the /boot directory, and it’s available in the Grub menu after reboot.

$ ls -1 /boot/*$(git describe --long | tr '[:upper:]' '[:lower:]')*
/boot/config-5.13.19-ubuntu-5.13.0-22.22-0-g3ab15e228151
/boot/initrd.img-5.13.19-ubuntu-5.13.0-22.22-0-g3ab15e228151
/boot/System.map-5.13.19-ubuntu-5.13.0-22.22-0-g3ab15e228151
/boot/vmlinuz-5.13.19-ubuntu-5.13.0-22.22-0-g3ab15e228151

Kernel ubuntu-5.13.0-22.22-0-g3ab15e228151 is, for all intents and purposes, the same as kernel 5.13.0-22-generic, so I expected it to be a “good” kernel, and it was.

For kernel Ubuntu-5.13.0-23.23 I did the same thing: starting from the git checkout. I skipped copying and editing the config file, because between minor releases I don’t expect there to be much change. I did run make olddefconfig for good measure, though. As expected, the keyboard and mouse didn’t work with the compiled ...-23 kernel.

Next up: using git bisect to find the exact commit where it went wrong. It’s got to be somewhere between ...-22 and ...-23!

The hunt for a kernel bug, part 2: an easy way to install mainline kernels

As I wrote previously, I’m suspecting a Linux kernel bug somewhere between versions 5.13.0-22 and 5.13.0-23, in the Ubuntu kernels. I wanted to know if the issue only surfaced in Ubuntu-flavored kernels, or also in the upstream (mainline) kernels from kernel.org.

There is an Ubuntu Mainline PPA with all the upstream kernels, but I found it a bit too opaque to use. Fortunately I found the Ubuntu Mainline Kernel Installer (UMKI), a tool for installing the latest Linux kernels on Ubuntu-based distributions.

Ubuntu Mainline Kernel Installer (UMKI)

The UMKI is pretty straightforward. It fetches a list of kernels from the Ubuntu Mainline PPA and a GUI displays available and installed kernels, regardless of how they were installed. It installs the kernel, headers and modules. There is also a CLI client.

To install the UMKI:

sudo add-apt-repository ppa:cappelikan/ppa
sudo apt update
sudo apt install mainline

With that out of the way, there’s the matter of deciding which kernels to try. The “interesting” Ubuntu kernels are 5.13.0-22 and 5.13.0-23, so the mainline kernels I definitely want to test, are around those versions. That means 5.13.0 and 5.13.1. I also want to try the latest 5.13.x kernel, so that’s 5.13.19, and the most recent stable kernel, 5.16.11 (as of 2022-03-01).

To summarize, I have tested these mainline kernels:

  • 5.13.0
  • 5.13.1
  • 5.13.19
  • 5.16.11

The result (after several reboots)? With all of them, my keyboard and mouse worked without a hitch. That means the issue most likely doesn’t occur in (stable) mainline kernels, only in kernels with additional patches from Ubuntu.

Up next: compiling kernels from source.

Lasciate ogne speranza, voi ch’intrate.

Dante Alighieri

Installing Ubuntu 20.04 LTS on 2011 MacBook Air

My laptop is a 2011 MacBook Air. I’m not a huge Apple fan, it’s just that at the time it had the most interesting hardware features compared to similar laptops. And it’s quite sturdy, so that’s nice.

Over the years I have experimented with installing Linux in parallel to the OS X operating system, but in the end I settled on installing my favorite Linux tools inside OS X using Homebrew, because having two different operating systems on one laptop was Too Much Effort. In recent times Apple has decided, in it’s infinite wisdom (no sarcasm at all *cough*), that it will no longer provide operating system upgrades for older hardware. Okay, then. Lately the laptop had become slow as molasses anyway, so I decided to replace OS X entirely with Ubuntu. No more half measures! I chose 20.04 LTS for the laptop because reasons. 🙂

The laptop was really slow…

According to the Ubuntu Community Help Wiki, all hardware should be supported, except Thunderbolt. I don’t use anything Thunderbolt, so that’s OK for me. The installation was pretty straightforward: I just created a bootable USB stick and powered on the Mac with the Option/Alt (⌥) key pressed. Choose EFI Boot in the Startup Manager, and from there on it’s all a typical Ubuntu installation.

screenshot
Startup Manager

I did not bother with any of the customizations described on the Ubuntu Wiki, because everything worked straight out of the box, and besides, the wiki is terribly outdated anyway.

The end result? I now have a laptop that feels snappy again, and that still gets updates for the operating system and the installed applications. And it’s my familiar Linux. What’s next? I’m thinking about using Ansible to configure the laptop.

To finish, I want to show you my sticker collection on the laptop. There’s still room for a lot more!

sticker collection on my laptop. Photo copyright: me.

How big is a clean install of Ubuntu Jammy Jellyfish (22.04)?

Because curiosity killed the cat, not because it’s useful! 😀

Start with a clean install in a virtual machine

I start with a simple Vagrantfile:

Vagrant.configure("2") do |config|
  config.vm.box = "ubuntu/jammy64"
  config.vm.provision "ansible" do |ansible|
    ansible.playbook = "playbook.yml"
  end
end

This Ansible playbook updates all packages to the latest version and removes unused packages.

- name: Update all packages to the latest version
  hosts: all
  remote_user: ubuntu
  become: yes

  tasks:

  - name: Update apt cache
    apt:
      update_cache: yes
      cache_valid_time: 3600
      force_apt_get: yes

  - name: Upgrade all apt packages
    apt:
      force_apt_get: yes
      upgrade: dist

  - name: Check if a reboot is needed for Ubuntu boxes
    register: reboot_required_file
    stat: path=/var/run/reboot-required get_md5=no

  - name: Reboot the Ubuntu box
    reboot:
      msg: "Reboot initiated by Ansible due to kernel updates"
      connect_timeout: 5
      reboot_timeout: 300
      pre_reboot_delay: 0
      post_reboot_delay: 30
      test_command: uptime
    when: reboot_required_file.stat.exists

  - name: Remove unused packages
    apt:
      autoremove: yes
      purge: yes
      force_apt_get: yes

Then bring up the virtual machine with vagrant up --provision.

Get the installation size

I ssh into the box (vagrant ssh) and run a couple of commands to get some numbers.

Number of installed packages:

$ dpkg-query --show | wc --lines
592

Size of the installed packages:

$ dpkg-query --show --showformat '${Installed-size}\n' | awk '{s+=$1*1024} END {print s}' | numfmt --to=iec-i --format='%.2fB'
1.14GiB

I need to multiply the package size with 1024 because dpkg-query outputs size in kilobytes.

Total size:

$ sudo du --summarize --human-readable --one-file-system /
1.9G	/

Get the installation size using Ansible

Of course, I can also add this to my Ansible playbook, and then I don’t have to ssh into the virtual machine.

  - name: Get the number of installed packages
    shell: dpkg-query --show | wc --lines
    register: package_count
    changed_when: false
    failed_when: false
  - debug: msg="{{ package_count.stdout }}"

  - name: Get the size of installed packages
    shell: >
      dpkg-query --show --showformat '${Installed-size}\n'
      | awk '{s+=$1*1024} END {print s}'
      | numfmt --to=iec-i --format='%.2fB'
    register: package_size
    changed_when: false
    failed_when: false
  - debug: msg="{{ package_size.stdout }}"

  - name: Get the disk size with du
    shell: >
      du --summarize --one-file-system /
      | numfmt --to=iec-i --format='%.2fB'
    register: du_used
    changed_when: false
    failed_when: false
  - debug: msg="{{ du_used.stdout }}"

The output is then:

TASK [Get the number of installed packages] ************************************
ok: [default]

TASK [debug] *******************************************************************
ok: [default] => {
    "msg": "592"
}

TASK [Get the size of installed packages] **************************************
ok: [default]

TASK [debug] *******************************************************************
ok: [default] => {
    "msg": "1.14GiB"
}

TASK [Get the disk size with du] ***********************************************
ok: [default]

TASK [debug] *******************************************************************
ok: [default] => {
    "msg": "1.82MiB /"
}
